ALLIED VR8300A0003B SG225-N GAS VALVE
MFR Part #: SG-225 N
SKU #: 1211735
Brand: Super Hot®
Super Hot® Saturn Series SG-225 N Gas Boiler, 85 % AFUE, 191250 Btu/hr, 225000 Btu/hr Btu, 2.8 gal Capacity, Steel
1 Year Parts and Controls, 10 Year Heat Exchanger
Integrated Boiler Controller, Zone Control Board with Transformer, Stainless Steel Burner, Combination Gas Valve, High Limit Sensor, Temperature/Pressure Gauge, Pressure Relief Valve, Drain Valve, Draft Hood, Blocked Vent Safety Switch, Flame Roll-Out Safety Switch and Automatic Vent Damper
For large and multi-family residential and commercial
AHRI Certified|ASME Specified|cCSAus Certified
Product Details
Attributes
Features
Resources
Super Hot® Gas Boiler, Series: Saturn, 56 kW, 65.9 kW, 1 ph Phase, 85 % AFUE, 191250 Btu/hr, 225000 Btu/hr, 2.8 gal Capacity, 19.1 gpm Flow Rate, 3.5 in-WC, 3/4 in NPT Gas Connection, Natural Gas Fuel, Electronic Intermittent Pilot Ignition, 166 MBtu/hr Net Rating, Steel, Baked Enamel, 30-1/4 in W
Saturn Series boilers offer more than just comfort. Allied Engineering's unique energy efficient double pass design provides the ultimate in quality construction, performance and reliability. Low operating cost and ease of installation make our boilers well-suited for both new construction and renovation.
AFUE Rating:85 %
BTU Rating:191250 Btu/hr, 225000 Btu/hr
Capacity:2.8 gal
Connection Type:3/4 in NPT Gas
Dimensions:30-1/4 in W
Finish:Baked Enamel
Flow Rate:19.1 gpm
Fuel Type:Natural Gas
Ignition Type:Electronic Intermittent Pilot
Material:Steel
Net Rating:166 MBtu/hr
Phase:1 ph
Power Rating:56 kW, 65.9 kW
Pressure Rating:3.5 in-WC
Series:Saturn
- Rugged industrial design steel fin tube heat exchanger built to ASME standards
- Compact, lightweight and durable
- Approved for combustible floor and closet, alcove installation
- PS or packaged boilers save installers time and labor by including system parts and a pump pre-wired and mounted
- Allied engineering uses an environmentally friendly construction that is designed for longevity and maximum efficiency
- Most components can be recycled after their long, trouble-free life
- Control, monitoring and safety devices are factory wired using plug-in connectors for quick installation and service
- Zone controller which handles up to four zones with separate plug-in for zone valves and LED lights to clearly show which zones are being heated
- If required, additional boards can be added to increase zone capacity
- Ideal for modular installations providing uninterrupted heating
- A durable steel casing and attractive baked enamel finish from our state of the art paint line protects the boilers internal workings
- Full length doors are supplied on all boilers up to SG270
- Control panel doors are supplied on boilers SG315 and over
