DELTA W6200GAS CP BALL VALVE - N.GAS DECK/WALL MOUNT CHROME
MFR Part #: W6200GAS
SKU #: 3096162
Brand: DELTA®
UPC: 778062022352
DELTA® W6200GAS Ball Valve Hose Cock, Polished Chrome, 1 Handles, Import, Commercial
10 Years
Commercial Applications
ADA Compliant | ANSI Z21.15/A117.1 | CSA 9.1 | CGA/AGA Approved | cCSAus Certified | ICC A117.1
Product Details
Attributes
Features
Resources
DELTA® Ball Valve Hose Cock, Lever, 1 Handles, 3/8 in, MNPT, 2-1/4 in Maximum Deck Thickness, Wall Mount, Brass, Polished Chrome, Import, Commercial
Mounting Type:Wall
Commercial/Residential:Commercial
Connection Size:3/8 in
Connection Type:MNPT
Finish/Color:Polished Chrome
Handle Type:Lever
Material:Brass
Number of Handles:1
- Floating ball-type design
- Universal 10 serration vandal resistant nozzle with 3.2mm(1/8 in) outlet-removable with flat on one side
- Vacuum valves supplied with corrosion resistant ball and FKM o-rings for improved durability
- Rated to maximum 125 psi testing pressure
- Colored index button to suit desired service
- Maintenance free- no need to regrease sealing surfaces or take valve apart
- Every ball valve carries its date of manufacture on the underside of the body
- Use of this ball valve above 40 psi requires special clamping procedures by others to ensure that any hoses attached to nozzle do not blow off
- Life cycle tested to up to 100,000 cycles
- No shank
- 3/8 in MIP inlet
- Non-removable lever handle
Product Details
DELTA® Ball Valve Hose Cock, Lever, 1 Handles, 3/8 in, MNPT, 2-1/4 in Maximum Deck Thickness, Wall Mount, Brass, Polished Chrome, Import, Commercial
Attributes
Mounting Type: Wall
Commercial/Residential: Commercial
Connection Size: 3/8 in
Connection Type: MNPT
Finish/Color: Polished Chrome
Handle Type: Lever
Material: Brass
Number of Handles: 1
Features
- Floating ball-type design
- Universal 10 serration vandal resistant nozzle with 3.2mm(1/8 in) outlet-removable with flat on one side
- Vacuum valves supplied with corrosion resistant ball and FKM o-rings for improved durability
- Rated to maximum 125 psi testing pressure
- Colored index button to suit desired service
- Maintenance free- no need to regrease sealing surfaces or take valve apart
- Every ball valve carries its date of manufacture on the underside of the body
- Use of this ball valve above 40 psi requires special clamping procedures by others to ensure that any hoses attached to nozzle do not blow off
- Life cycle tested to up to 100,000 cycles
- No shank
- 3/8 in MIP inlet
- Non-removable lever handle
