WHITE RODGERS 50A55-3797 INTEGRATED 1-STAGE FURNACE CONTROL
MFR Part #:Â 50A55-3797
SKU #:Â 1688111
Brand: White-Rodgers™
White-Rodgers™ 50A55-3797 Replacement Integrated Furnace Control, 25 V AC, 0.45 A
Flash Code Diagnostics
For Trane Single Stage HSI Controls
CSA Certified
Product Details
Attributes
Features
Resources
White-Rodgers™ Replacement Integrated Furnace Control, Accessory Type: Replacement Integrated Furnace Control, 25 V AC, 0.45 A, Liquid Propane/Natural Gas Gas, 17 s Igniter Warm-Up, Surface Mounting, 4.4 in Width, 1-1/4 in Depth, 5.9 in Height, Import
The 50A55-3797 is an automatic gas interrupted ignition control that employs a microprocessor to continually monitor, analyze, and control the proper operation of the gas burner, inducer, and fan. signals interpreted during continual surveillance of the thermostat and flame sensing element initiate automatic ignition of the burner, sensing of the flame, and system shutoff during normal operation. these controls incorporate system fault analysis for quick gas flow shutoff , coupled with automatic ignition retry upon sensing a fault correction. it is designed as a replacement for the following controls.
Amperage Rating:.45 A
Depth:1-1/4 in
Domestic/Import:Import
Height:5.9 in
Igniter Warm-Up Time:17 s
Mounting Type:Surface
Voltage Rating:25 V AC
Width:4.4 in
Accessory Type:Replacement Integrated Furnace Control
Gas Type:Liquid Propane/Natural Gas
- Fused to protect low voltage system transformers
- 120 VAC ignitor output
- 120 VAC humidifier output
- 120 VAC electronic air cleaner output
- 120 VAC 2-speed PSC circulator output
- 5 A fuse protection
- Furnace status LED
- Heat fan off delay (dipswitch selectable)
- -40 to 176 deg F
- 5 to 93 percent relative humidity
- 1.5 A valve relay
- 6 A ignitor relay
- 2.2 FLA to 3.5 LRA inducer relay
- 14.5 FLA to 25 LRA circulator relay
- 1 uA DC min current
- 0.10 uA DC max current
- 100 M ohm leakage resistance
- Maximum timing specification
- 0.8 sec flame establishing
- 2 sec flame failure response
Product Details
White-Rodgers™ Replacement Integrated Furnace Control, Accessory Type: Replacement Integrated Furnace Control, 25 V AC, 0.45 A, Liquid Propane/Natural Gas Gas, 17 s Igniter Warm-Up, Surface Mounting, 4.4 in Width, 1-1/4 in Depth, 5.9 in Height, Import
The 50A55-3797 is an automatic gas interrupted ignition control that employs a microprocessor to continually monitor, analyze, and control the proper operation of the gas burner, inducer, and fan. signals interpreted during continual surveillance of the thermostat and flame sensing element initiate automatic ignition of the burner, sensing of the flame, and system shutoff during normal operation. these controls incorporate system fault analysis for quick gas flow shutoff , coupled with automatic ignition retry upon sensing a fault correction. it is designed as a replacement for the following controls.
Attributes
Amperage Rating:Â .45 A
Depth:Â 1-1/4 in
Domestic/Import:Â Import
Height:Â 5.9 in
Igniter Warm-Up Time:Â 17 s
Mounting Type:Â Surface
Voltage Rating:Â 25 V AC
Width:Â 4.4 in
Accessory Type:Â Replacement Integrated Furnace Control
Gas Type:Â Liquid Propane/Natural Gas
Features
- Fused to protect low voltage system transformers
- 120 VAC ignitor output
- 120 VAC humidifier output
- 120 VAC electronic air cleaner output
- 120 VAC 2-speed PSC circulator output
- 5 A fuse protection
- Furnace status LED
- Heat fan off delay (dipswitch selectable)
- -40 to 176 deg F
- 5 to 93 percent relative humidity
- 1.5 A valve relay
- 6 A ignitor relay
- 2.2 FLA to 3.5 LRA inducer relay
- 14.5 FLA to 25 LRA circulator relay
- 1 uA DC min current
- 0.10 uA DC max current
- 100 M ohm leakage resistance
- Maximum timing specification
- 0.8 sec flame establishing
- 2 sec flame failure response
