GRUNDFOS 52722557 1/6HP 115V 3 SPEED CI CIRC PUMP UPS50-44F
Product Details
Attributes
Features
Resources
Grundfos Circulator Pump, Series: UPS, 63.8 gpm, 14.44 ft Maximum Head, 194 W, 115 V AC, 1.7 A, 60 Hz, 1 ph, 145 psi Maximum, 104 deg F Ambient, 7-1/2 in W x 8-1/2 in H
The UPS 50-44 F is a canned rotor circulator pump, meaning the pump and motor are integrated into a single, seal-less unit. With no mechanical shaft seal and only two gaskets, the design minimizes leakage risk and reduces maintenance requirements. The pump bearings are lubricated by the pumped liquid. Ideal for hydronic heating systems, HVAC circulation, and domestic hot water recirculation.
- Ceramic shaft and radial bearings
- Carbon axial bearing
- Stainless steel rotor can and bearing plate
- Corrosion resistant impeller, composite, PES
- Cast iron pump housing
- 1 ph motor, no additional motor protection is required
Product Details
Grundfos Circulator Pump, Series: UPS, 63.8 gpm, 14.44 ft Maximum Head, 194 W, 115 V AC, 1.7 A, 60 Hz, 1 ph, 145 psi Maximum, 104 deg F Ambient, 7-1/2 in W x 8-1/2 in H
The UPS 50-44 F is a canned rotor circulator pump, meaning the pump and motor are integrated into a single, seal-less unit. With no mechanical shaft seal and only two gaskets, the design minimizes leakage risk and reduces maintenance requirements. The pump bearings are lubricated by the pumped liquid. Ideal for hydronic heating systems, HVAC circulation, and domestic hot water recirculation.
Attributes
Features
- Ceramic shaft and radial bearings
- Carbon axial bearing
- Stainless steel rotor can and bearing plate
- Corrosion resistant impeller, composite, PES
- Cast iron pump housing
- 1 ph motor, no additional motor protection is required
