ILSCO ACON-500 ALUMINUM CMP 500 T CULUS OFFSET PIN PIGTAIL ADAPTER
MFR Part #: ACON-500
SKU #: 3274676
Brand: ILSCO®
UPC: 783669021462
ILSCO® ACON-500 ACON Dual Rated Pigtail Adaptor, 500 kcmil Conductor, Die Code: 300, 0.68 in Dia Pin x 1.69 in L Pin, Aluminum
UL 941 R | UL/cUL 486A/B Listed | UL File Number E62537
Product Details
Features
Resources
ILSCO®, ACON-500, Pigtail Adaptor, Dual Rated, Series: ACON, 500 kcmil Conductor, Die Code: 300, Pink Color Code, 0.68 in Pin Diameter, 1.69 in Pin Length, 1.71 in Barrel Length, 600 V, Specifications: Tin Plated, 90 deg C Temperature Rating, 180 deg Connecting Angle pin size, Aluminum, 1.32 in OD Dimensions
- Clearly marked with wire size and die index for ILSCO tools, proper number & location of crimps
- Prefilled with DE-OX
- Provides maximum conductivity and excellent crimping characteristics
- Provides easy conductor insertion
- Ensures reliability for aluminum or copper conductors
- Provides easy identification and tooling recommendation
- Prevents oxides from forming
- Prevents foreign materials from entering the connector prior to usage and color code identifies the proper compression die
- ACON configuration allows connectors to be rotated for parallel applications where spacing does not fit straight pin connectors
- 350 kcmil pin size
Product Details
ILSCO®, ACON-500, Pigtail Adaptor, Dual Rated, Series: ACON, 500 kcmil Conductor, Die Code: 300, Pink Color Code, 0.68 in Pin Diameter, 1.69 in Pin Length, 1.71 in Barrel Length, 600 V, Specifications: Tin Plated, 90 deg C Temperature Rating, 180 deg Connecting Angle pin size, Aluminum, 1.32 in OD Dimensions
Features
- Clearly marked with wire size and die index for ILSCO tools, proper number & location of crimps
- Prefilled with DE-OX
- Provides maximum conductivity and excellent crimping characteristics
- Provides easy conductor insertion
- Ensures reliability for aluminum or copper conductors
- Provides easy identification and tooling recommendation
- Prevents oxides from forming
- Prevents foreign materials from entering the connector prior to usage and color code identifies the proper compression die
- ACON configuration allows connectors to be rotated for parallel applications where spacing does not fit straight pin connectors
- 350 kcmil pin size
